12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record

12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record
12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record 12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record 12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record

Large Image :  12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record

Product Details:

Place of Origin: China
Brand Name: WINSAFE
Certification: CE,FCC
Model Number: LTC-A1202 + BLS-200

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Packaging Details: Netural Packing
Delivery Time: 3-5 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs/month
Detailed Product Description
Video Inferface: USB 3.0 / DVI-I / USB 3.0 Dual Stream: Support
Video Compression: H.264 Audio Compression: AAC
Tracking Camera Lens: F=3.9mm - 46.8mm Tracking Camera Zoom: Optical:12X, Digital:12X
Full View Camera Lens: 2.4mm Field Of Full View Camera: Horizontal:86°; Vertical:52°
High Light:

usb ptz hd camera

,

usb conference room camera

12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record



The system supports to manage its tracking and other features through ethernet, connection,configuration and communication have never been so easy. It supports standard VISCA & Pelco D protocols to coummunicate eamlessly with your control device.



This smart lecturer tracking and board writing detection system consists of a USB HD lecturer tracking camera(USB3.0, DVI, SDI supported) and an IP board writing detecting sensor, configuration and installation of the system has never been so easy and effective; unique performance of the system is that, after the board writing detecting sensor detects writing actions on the board, it triggers the lecturer tracking camera to automatically move to the pre-defined board position and start tracking lecturer there. If undetected, the lecturer tracking camera can either keep tracking lecturer to return to pre-defined position and start tracking there.



USB 3.0



12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record 0



The lecturer tracking camera comes with USB3.0 and many other video interfaces. Giving it more flexibility to work with different recording solutions.



Precise lock and track capability



12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record 1



Tracking is based on both face detection and motion detection technology, whith ensures smooth and precise lock & track performance even in comprehensive scenarios.



Unmanned and standalone tracking



12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record 2



Tracking performance is realized by the system itself, both its two lens manage the tracking algorithm, there is no need to have manual operation or have extra devices / sensors to assist tracking



Smart tracking performance



12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record 3



The system does not track on minor movements, it have tilt motion and auto zoom function to keep tracking lecturer properly once lecturer moves closer / farther, once object is lost, the system moves back to pre-defined position and keeps tracking at the position.



Board Writing triggers tracking



12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record 4



When board writing detecting camera detects sensor actions, it triggers the lecturer tracking camera to automatically move to pre-defined board position and start tracking lecturer there. If undetected, tracking camera can either stay or return to pre-defined position



Easy connection, configuration and communication



12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record 5



LTC2-A1201/USB 3.0 Lecturer Tracking PTZ Camera Specification



Model No. LTC2-A1202
Tracking Camera
Image Sensor 1/2.8" Exmor CMOS, 2.14MP
Lens f=3.9mm-46.8mm; F1.6-F2.8
Zoom Optical:12X, Digital:12X
Field of View 72.5° - 6.3°
Focus Auto, Manual, PTZ Trigger AF, One Push
Mini.illumination 0.5Lux(Color), 0.1Lux(B/W)
Shutter Speed 1/1 - 1/10,000s
Gain Auto / Manual
White Balance Auto,Indoor, Outdoor, One Push, Manual, Automatic Tracking
AE Control Auto, Manual, Shutter Priority, Iris Priority
S/N Ratio Above 50dB
Full View Camera
Image Sensor 1/2.8" Exmor CMOS
Effective Pixel 2.15MP
White Balance Auto
Exposure Auto
Field of View Horizontal:86°; Vertical"52°
Lens 2.4mm
PTZ
Pan/Tilt Angle Range Pan: -170° - +170° ; Tilt: -30° - +90°
Pan/Tilt Speed Pan: 0.1° - +120°/s ; Tilt: 0.1° - +90°/s
Preset Number 256
Control Interface RS232/RS485/USB3.0
Ethernet RJ45,100M
Control Protocol PELCO-D / VISCA / UVC
Network
Image Resolution 1920x1080 @ 60fps
Frame Rate 1080P60/1080P50/1080P30/108025
1080I60/1080I50/720P60/720P50
Video Compression H.264
Audio Compression AAC
Protocol ONVIF / RTSP / RTMP / TCP / UDP
Dual Stream Support
Video Interface 3G-SDI / DVI-I / USB3.0
General
Power Supply DC12V
Power Consumption <20W
Working Temp 0°C - +40°C
Storage Temp -20°C - +60°C
Dimension 243mm(L) x 245mm(W) x 163mm(H)
Weight 1.2KG
Color Grey





Board Writing Detecting System/BLS-200



Model No. BLS-200
Image Sensor 1/3" Exmor CMOS
Effective Pixel 4.0MP(2560x1440)
Min.illumination 1Lux @ F2.0
S/N Ratio Above 50dB
Gain Auto/Manual
Shutter Speed 1/30 - 1/10,000s
White Balance Auto/Manual
Focal 2.4mm
View Angle 90°(wide) - 50°(tele)
Aperture F2.0
Video Compression H.264
Kbps 32Kbps-8Mbps
Video Frame Rate 720p30, 1080p30
Ethenet 10-100M, Support POE
Power Supply DC12V, POE
Power Consumption Below5W
Working Temp 0°C - +40°C
Humidity Below 90%(No condensation)
Dimension φ93mm * 81mm
Weight 0.33kg



LTC-A1202 Dimension



12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record 6  12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record 7



LTC-A1202 Bracket



 12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record 8   12X 1080P USB3.0 Lecturer Tracking PTZ Camera For Education Record 9
