IP66 Weatherproof Wide Voltage Input 60M IR Distance HD-SDI / CVBS Vehicle PTZ Camera

China IP66 Weatherproof Wide Voltage Input 60M IR Distance HD-SDI / CVBS Vehicle PTZ Camera supplier
IP66 Weatherproof Wide Voltage Input 60M IR Distance HD-SDI / CVBS Vehicle PTZ Camera supplier IP66 Weatherproof Wide Voltage Input 60M IR Distance HD-SDI / CVBS Vehicle PTZ Camera supplier

Large Image :  IP66 Weatherproof Wide Voltage Input 60M IR Distance HD-SDI / CVBS Vehicle PTZ Camera

Product Details:

Place of Origin: CHINA
Brand Name: WINSAFE
Certification: CE/FCC
Model Number: AC3-S3002H-IR

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Neutral Packing
Delivery Time: 5 - 8 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 6000PCS/Month
Contact Now
Detailed Product Description
AC3-S2008H-IR: 20X Optical Zoom AC3-S3002H-IR: 30X Optical Zoom
Materia: Aluminum PTZ Case Color: Black Or White
Voltage: DC10.8 - 28V OSD Menu: English
Protocol: RS-485 Weight: 2.1kg

IP66 Weatherproof Wide Voltage Input 60M IR Distance HD Vehicle PTZ Cameras



Features

※ 1/2.8" CMOS, 2.13MP, 30X/20X optical zoom
※ Support CVBS and SDI output
※ Efficient 60M IR distance
※ Wide dynamic range, ICR day/night
※ Digital image stabilization
※ Protection index: IP66
※ Self-adaption of protocol & baud rate
※ 10.8-28V voltage input
※ Auto power-of with low power supply



Technical Specification

Model No. AC3-S2008H-IR AC3-S3002H-IR
Camera
Image Sensor 1/2.8" Progressive Scan CMOS, 2.13MP
Active Pixel 1920(H) x 1080(V)
Signal System(HD) HD:1080p30 / 1080p25 / 1080i60/ 1080i50 / 720p60 / 720p50 / 720p30 / 720p25
Signal System(SD) PAL / NTSC
Min.Illumination Color:0.0013Lux, B/W:0.0008Lux
White Balance Auto
Focus Auto / Manual
Exposure Auto / Manual
S/N Ratio Note less than 50 Db
BLC On / Off
WDR On / Off
Digital Noise Reduction 1 - 5Steps/OFF
Digital Image Stabilization No On/Off
Day/Night Auto / Manual
PTZ
Optical Zoom 20X 30X
Zoom 12X
Focal f=4.7mm - 94mm f=4.3mm - 129mm
IRIS F1.6 to F3.5 F1.6 to F4.7
View Angle 59.5° (wide) to 3.3° (tele) 53.7° (wide) to 2.3° (tele)
PTZ
Pan Range 360° Continuous
Pan Speed 0.1° - 60°/s, adjustable,Preset Speed:60°/s
Tilt Range - 15 ° - 90° with auto flip
Tilt Speed 0.2° - 60°/s, adjustable, Preset Speed:60°/s
Preset Number 256
Preset Precision ±0.2°
IR Light
IR Wave Length 850nm
Range 60m
Switch Auto / Manual
General
OSD Lanuage English
Video Interface(HD) HD-SDI
Video Interface(SD) CVBS
Comm. Interface RS-485
Comm.Protocol PELCO-P / PLECO-D(self-adaptive)
Protocol 2400bps, 4800bps,9600pbs,19200bps(self-adaptive)
Address 0-255
Voltage DC 10.8 - 28V
Power Min:9W; Max:20W
Working Temperature -35°C - +65°C
IP Code IP66
Dimensions Standard(Without Damper): Φ136(mm) x 185(mm)
Weight

Standard(Without Damper): 2.1(±0.2)kg

IP66 Weatherproof Wide Voltage Input 60M IR Distance HD-SDI / CVBS Vehicle PTZ Camera
