| Model No. | WS-HU500 |
| OS |
| OS | Linux 3.10.73 |
| Booting time | < 8 s |
| Language | English |
| Video |
| Recording Resolution | 1920x1080/ 1280x720/ 640x360 |
| Frame rate | 30 fps@1080p |
| Video input | 1x digital Camera for 1080p/720p/360p recording, available for external camera |
| Video output | 2 inch LCD screen |
| Record mode | Record audio and video at the same time |
| Compression | H.264 (High profile up to level 4.1) |
| Audio |
| Audio input | 1x MIC input, support intercom connection with USB |
| Compression | PMC |
| Audio record | Support |
| Video process |
| Live video resolution | 1920x1080/ 1280x720/ 640x360 |
| Photograph | 1920x1080 ～ 8640x4752 |
| Snap | Support snapping during recording(the photo resolution base in recording) resolution) |
| Storage | Built in 16GB TF card (available for 16～128GB) |
| Light source |
| Flash light | To increase brightness when you are recording or taking a photo |
| Laser | Fix the view when you record |
| IR | Up to 10 Meters with visible shape image at night |
| Two way radio |
| Talk back | Support two way radio between different devices(only for 4G/3G device) |
| Talk back in platform | Support two way radio between device and platform(only for 4G/ 3G device) |
| Lens/Alarm/Interface/GPS |
| Len's angle | >125° |
| Alarm input | Support alarm input and the alarm can be show in platform |
| USB | 1x USB,for charging, communication with PC, upgrade OS, connect external camera etc |
| GPS | Optional module for BDS/GPS/GLONASS, to record location and speed |
| Network |
| Protocol | TCP/IP |
| 3G/4G | Optional, built in 3G/4G module(HSUPA/HSDPA/WCDMA/EVDO/TD-SCDMA/FDD-LTE/TDD-LTE) |
| WiFi | Optional, support WiFi connection and AP |
| Firmware |
| OSD | Display and record time, license ID, officer ID, location, speed |
| Overwrite | Support |
| Play back | Support play back, file listed by time and alarm |
| Play speed | Support from 1/128 to 128 |
| Pre-recording/ pist-recording | Maximum 20s pre-recording and post-recording |
| Dewarp | Support dewarp to make the picture more accurate and realistic |
| Safe mode | Need password to enter Setting or Playback in safe mode |
| Record encryption | Support Record encryption, encrypted video can be played in special player |
| Log | Record power on/off, setting change, start record, alarm etc |
| Software |
| Hplayer | Player software, play multiple cameras together, can also play the encrypted file |
| CMSV6 | Used for 4G/3G model only, support live view/live tracking/historical track |
| Upgrade |
| Firmware maintain | Firmware can be upgraded though USB |
| Working condition |
| Temperature | -40℃--60℃ |
| Humidity | 40%～80% |
| Other |
| Time | synchronize with GPS, internet, PC |
| Dual bit stream | Two different bit stream for recording and live streaming via 4G/3D |
| Default | Can set to default setting |
| Indicator | Power, Record, Snap, Audio record |
| Battery capacity | 2600mAh x2 Replaceable battery, keep NON-4G device running for about 8h, keep 4G device running for about
6h; Charging time is about 4h |
| Backup battery | 60mA (Optional, keep device running during switch battery) |
| Size | 88.3 x 59.8 x 34.4mm |
| Weight | About 165g |
