Product Details:
Payment & Shipping Terms:
|
Program: | Hi3518E + OV9712 | Model No.: | WS-NVR418-13 |
---|---|---|---|
NVR: | 4 Channel | Size: | 280*230*57mm |
IR Distance: | 20-30M | Monitor: | 10.1 Inch |
Mobile: | Android / IOS | ||
High Light: | Wifi Security Camera System,Wireless IP Camera Kit |
1.3MP Wireless Home Surveillance Systems 4 Channel NVR Kit 20M - 30M Infrared Distance
Packing Infomration
※ 4CH NVR with 2pcs Antenna
※ 960P 1.3MP wifi IP Camera: 4PCS
※ Power: 5PCS
※ CD: 1PCS
※ Mouse: 1PCS
※ Screw package: 5PCS
※ Simple instructions: 1PCS
Features
※ Power to the image, do not do any settings, truly fool-operation
※ 4CH WIFI NVR with 4 PCS WIFI IP camera, you can allow customers to follow their own according to their needs expand
※ Support phone operator APP
※ Support the post alarm, motion detection, etc.
Specification
Model No. | WS-NVK418M-13 |
Video & audio input | |
Network video input | 4CH NVR,With 10.1”LED,Up Down Left Right,Rotate 180 Degrees |
Video & audio output | |
HDMI output | 800x600,1024x768,1280x1024,1440x900,720P,1080P |
VGA output | 800x600,1024x768 |
Mobile phone | Support Android /Apple System |
Audio output | NO |
Video & audio code and decode parameters | |
Record resolution | D1/HD1/CIF/720P/960P/1080P |
Playback resolution | 720P 100/120FPS 1080P 50/64FPS |
Motion detection | Motion Detection |
Synchronously playback channels | 1/4CH |
Record management | |
Record & Snapshot mode | manual recording, regular recording, motion recording, alarm recording, events recording |
Playback mode | regular playback,alarm playback,motion detection playback,events playback |
Backup mode | regular backup, events backup, manual backup |
Hard driver | |
Mode | 1*SATA |
HDD capacity | each port support max 4TB HDD |
External port | |
Voice intercom | NO |
Internet port | 1PCS RJ45 10M / 100M adaptive Ethernet port |
USB port | 1*USB2.0 |
WIFI port | Built-in wireless router,With 2pcs Antenna |
WIFI Distance | 100M(Open area),Wall:20-30M |
Network Management | |
Network protocol | Built-in wireless router,With 2pcs Antenna,The image is automatically |
Other | |
Power supply | DC12V |
Power consumtion(without HDD | ≤16W |
Work temperature | (-10℃--+55℃) |
Work humidity | 10%--90% |
Case | 0.8U |
Size(W*L*H(cm)) | 280*230*57mm |
Net weight(without HDD) | 1.6kg |
Gross weight(without HDD) | 2.39kg |
Color box size(L*W*H(cm)) | 330*320*98mm |
Packing(pcs/carton) | 5 |
Carton size (L*W*H(cm)) | 50*34*35cm |
Gross weight(kg) | 12.46kg |
WIFI IP CAMERA Parameter | |
Model No. | WS-IPC-418M-13 |
Program | HI3518E+OV0130 |
System structure | Embedded RTOS design,Dual-Core 32-bit DSP,Pure hardware compression, watchdog; |
Sensor | 1/4" OV0130 CMOS sensor |
Led | 36PCS IR LED+15PCS IR LED |
Lens | 4.0MM 2.0MP HD Lens |
IR Distance | 20-30M |
Minimum illumination | Colo 0.001Lux@F1.2; |
Video Processing | H.264 coding,MJPEG coding AVI format;Support Stream 0.1M~16Mpbs Adjustable; |
Image Frame Rate | PAL:1~25 Frame/second,NTSC: 1~30 Frame/second;Adjustable |
Video Streams | Main stream: 1280*960 |
Sub-stream: 1280*720 ,704*576,640*480 | |
Audio Processing | N/A |
Network Interface | 1PCS RJ45 Ethernet port, 10m / 100M Adaptive;Support WIFI,Automatic code, automatic image |
WIFI Port | Support WIFI, With 1pcs Antenna |
WIFI Distance | 100M(Open area),Wall: 20-30M |
Reset Interface | N/A |
TF card interface | N/A |
Auto Iris Interface | N/A |
Signal Interface | Support photoresistor input signal and the IR-CUT, infrared light linkage; |
POE | N/A |
Phone monitoring | N/A |
Lightning Protection | Power, network, POE comprehensive lightning,In line with national standards GB / T17626.5, International standard IEC61000-4-5. |
Working environment | (-10℃~+60℃) |
Power supply | DC12V power input(12V/1A) |
Weight | 0.5KG |
