Product Details:
Payment & Shipping Terms:
|
| NVR: | NVR Built In Monitor | NVR Display: | 10.1" LED |
|---|---|---|---|
| NVR Size: | 280 X 230 X 57mm | Weight: | 1.6kg |
| Program: | HI3518E + OV9712 | WiFi: | Support |
| WiFi Distant: | Max : 100M (No Wall) | IR Distance: | Max : 20M |
| High Light: | IP Surveillance Camera System,Wireless IP Camera Kit |
||
Professional 4Pcs Wifi Wireless IP Camera System With Manual / Regular Recording
Packing Infomration
※ 4CH NVR with 2pcs Antenna
※ 720P 1.0MP wifi IP Camera: 4PCS
※ Power: 5PCS
※ CD: 1PCS
※ Mouse: 1PCS
※ Screw package: 5PC
※ Simple instructions: 1PCS
Features
※ Power to the image, do not do any settings, truly fool-operation
※ 4CH WIFI NVR with 4 PCS WIFI IP camera, you can allow customers to follow their own according to their needs expand
※ Support phone operator APP
※ Support the post alarm, motion detection, etc.
Specification
| Model No. | WS-NVK415M-10 |
| Video & audio input | |
| Network video input | 4CH NVR,With 10.1”LED,Up Down Left Right,Rotate 180 Degrees |
| Video & audio output | |
| HDMI output | 800x600,1024x768,1280x1024,1440x900,720P,1080P |
| VGA output | 800x600,1024x768 |
| Mobile phone | Support Android /Apple System |
| Audio output | NO |
| Video & audio code and decode parameters | |
| Record resolution | D1/HD1/CIF/720P/960P/1080P |
| Playback resolution | 720P 100/120FPS 1080P 50/64FPS |
| Motion detection | Motion Detection |
| Synchronously playback channels | 1/4CH |
| Record management | |
| Record & Snapshot mode | manual recording, regular recording, motion recording, alarm recording, events recording |
| Playback mode | regular playback,alarm playback,motion detection playback,events playback |
| Backup mode | regular backup, events backup, manual backup |
| Hard driver | |
| Mode | 1*SATA |
| HDD capacity | each port support max 4TB HDD |
| External port | |
| Voice intercom | NO |
| Internet port | 1PCS RJ45 10M / 100M adaptive Ethernet port |
| USB port | 1*USB2.0 |
| WIFI port | Built-in wireless router,With 2pcs Antenna |
| WIFI Distance | 100M(Open area),Wall:20-30M |
| Network Management | |
| Network protocol | Built-in wireless router,With 2pcs Antenna,The image is automatically |
| Other | |
| Power supply | DC12V |
| Power consumtion(without HDD | ≤16W |
| Work temperature | (-10℃--＋55℃) |
| Work humidity | 10％--90％ |
| Case | 0.8U |
| Size(W*L*H(cm)) | 280*230*57mm |
| Net weight(without HDD) | 1.6kg |
| Gross weight(without HDD) | 2.39kg |
| Color box size(L*W*H(cm)) | 330*320*98mm |
| Packing(pcs/carton) | 5 |
| Carton size (L*W*H(cm)) | 50*34*35cm |
| Gross weight(kg) | 12.46kg |
| WIFI IP CAMERA Parameter | |
| Model No. | WS-IPC-409-10 |
| Program | HI3518E+OV9712 |
| System structure | Embedded RTOS design,Dual-Core 32-bit DSP,Pure hardware compression, watchdog; |
| Sensor | 1/4" OV9712 CMOS sensor |
| Led | 36PCS IR LED |
| Lens | 4.0MM 2.0MP HD Lens |
| IR Distance | 20-30M |
| Minimum illumination | Colo 0.001Lux@F1.2； |
| Video Processing | H.264 coding,MJPEG coding AVI format；Support Stream 0.1M~16Mpbs Adjustable； |
| Image Frame Rate | PAL:1~25 Frame/second,NTSC: 1~30 Frame/second;Adjustable |
| Video Streams | Main stream: 1280*720 |
| Sub-stream: 704*576,640*480,352*288 | |
| Audio Processing | N/A |
| Network Interface | 1PCS RJ45 Ethernet port, 10m / 100M Adaptive；Support WIFI,Automatic code, automatic image |
| WIFI Port | Support WIFI, With 1pcs Antenna |
| WIFI Distance | 100M(Open area),Wall: 20-30M |
| Reset Interface | N/A |
| TF card interface | N/A |
| Auto Iris Interface | N/A |
| Signal Interface | Support photoresistor input signal and the IR-CUT, infrared light linkage; |
| POE | N/A |
| Phone monitoring | N/A |
| Lightning Protection | Power, network, POE comprehensive lightning,In line with national standards GB / T17626.5, International standard IEC61000-4-5. |
| Working environment | (-10℃~+60℃) |
| Power supply | DC12V power input(12V/1A) |
| Weight | 0.5KG |
